Phase terminal, with screwless contacts, 12 terminals

Item no. 2016270 | EAN 4012196474981

2016270 / KL-DBP12x02GR
12
10 mm²
16 mm²
Product description
Product description
Phase connection terminal with 12 x 2.5 mm² screwless terminal points; two 4 mm² screwless terminal points and two 16/25 mm² screw connection terminal points.

For snapping onto 15 mm hat rails to DIN EN 50022.
  • Verband der Elektrotechnik, Elektronik, Informationstechnik e.V., Germany
  • Halogen-free; without chlorine, fluorine and bromine
  • Flame resistant 960 °C
  • Communautés Européennes, EC declaration of conformity according to EC directives
Technical data

Technical data

Closing plate required no
Colour Grey
Dimension 12x2,5mm²
Explosion-tested version no
Height 20 mm
Length 85 mm
Material Polyamide
No. of terminals 12
Nominal cross-section, max. 16 mm²
Nominal cross-section, min. 10 mm²
Pole number 12
Suitable for flexible conductors no
Suitable for multi-wire conductors no
Suitable for solid conductors no
All types

All types

Types No. of terminals Nominal cross-section, min. Nominal cross-section, max. Item no. Quantity SSU
KL-DBP12x02GR 12 10 mm² 16 mm² 2016270
10 piece
